Kaleidescape Terra Prime Movie Server 120TB HDD
$34,99500
Custom order item, not avalible for online purchase.
Terra Prime Movie Servers
Terra and Terra Prime® movie servers store Kaleidescape movies, TV series, and concerts. Kaleidescape movies are downloaded asynchronously and then played back from local storage. This enables playback with full fidelity, irrespective of internet connectivity.
Kaleidescape movies are played back on Strato movie players. Standalone Strato players contain a limited amount of local storage. But when they are grouped with Terra, the internal storage is disabled, and the full Kaleidescape experience is enabled, including the list view and iconic cover shuffle view, which look and work better with larger movie libraries.
The Kaleidescape Terra Prime comes with 120TB HDD of storage. Up to four compact Terras can be combined in a single system for more storage.
Details & Specs
| Model | Terra Prime HDD |
|---|---|
| Shared Specifications | |
| Movie Server | Downloads Kaleidescape high-bitrate 4K movies in as little as 8 minutes Compact serves up to 5 simultaneous playbacks of Kaleidescape 4K movies Full-size serves up to 10 simultaneous playbacks of Kaleidescape 4K movies |
| Network | 2.5 Gigabit Ethernet (recommended) 1 Gigabit Ethernet (minimum) |
| Other Connection | USB 3.0 (reserved) |
| Environment | Operating: 41 to 95°F (5 to 35°C) Storage: -4 to 140°F (-20 to 60°C) Relative humidity: 20 to 80% (operation), 5 to 90% (storage) Maximum operating altitude: 10,000ft (3,048m) |
| Ventilation | Airflow: Full Size - 10 CFM (17 m3/hr) max Compact - 5 CFM (8.4 m3/hr) max Minimum 1" (2.5cm) space at the front Minimum 2" (5cm) space at the rear |
| Certifications | CSA 62368-1 IEC 62368-1 FCC CLASS B CE RoHS Compliant |
| Full Size - 88 & 48 TB | |
| Dimensions (WxHxD) | 17.0 x 3.5 x 10.0" 43.2 x 8.9 x 25.4 cm |
| Weight | 15.4 lb (7.0 kg) with no drives installed 21.6 lbs (9.8 kg) with four hard drives |
| Fan & Drive Noise | Typical: 29 dB(A) |
| Power | Max consumption: 48W Typical: 43W External power adapter: 2.6 x 1.4 x 6.5" (6.6 x 3.5 x 16.5 cm) 150W with detachable line cord 100-240V, 50-60Hz universal input 12VDC @ 12.5A |
| Storage | Four removable 22TB or 12TB hard drives (88TB or 48TB total) 88TB configuration stores: ~1,450 Kaleidescape high-bitrate 4K movies ~2,300 HD movies ~13,500 SD movies 48TB configuration stores: ~800 Kaleidescape high-bitrate 4K movies ~1,300 HD movies ~7,200 SD movies |
| Rack Mount (sold separately) | Rack shelf available for mounting one unit in a 19" rack 2RU space |
| Compact - 22 & 8 TB | |
| Dimensions (WxHxD) | 7.87 x 1.52 x 14.33" 20.0 x 3.9 x 36.4 cm |
| Weight | 7.2 lbs (3.3 kg) |
| Fan & Drive Noise | Typical: 25 dB(A) |
| Power | Max consumption: 29W Typical: 24W External power adapter: 2.6 x 1.4 x 6.5in (6.6 x 3.5 x 16.5 cm) 150W with detachable line cord 100-240V, 50-60Hz universal input 12VDC @ 12.5A |
| Storage | One integrated 22TB or 8TB hard drive 22TB configuration stores: ~350 Kaleidescape high-bitrate 4K movies ~600 HD movies ~3,300 SD movies 8TB configuration stores: ~130 Kaleidescape high-bitrate 4K movies ~220 HD movies ~1,200 SD movies |
| Rack Mount (sold separately) | Rack shelf available for mounting one or two units in a 19" rack 1RU space |
