Moon by Simaudio 390 Preamp
$6,40000
Custom order item, not avalible for online purchase.
Please Call/Email to order - Item Not Available for Online Purchase
405-795-3462
Design features
-
ESS PRO SABRE DAC chipset
-
Up to 32 bit / 384 kHz
-
Synchronized multi-room playback
-
Stream local source to other Zones
-
MQA and DSD decoding
-
Menu-configurable MM/MC phono stage
-
Headphone amplifier
-
MHP (MOON Hybrid Power – Universal Power Supply)
-
Optional HDMI inputs: (4k, HDCP 2.3, Deep colour)
Specifications
-
Analog input impedance22 kΩ
-
Max analog input5 V RMS
-
Max gain10 dB
-
Output impedance50 Ω
-
Crosstalk @ 1 kHz-116 dB
-
Frequency response10Hz - 200kHz -0.5 dB/-3 dB
-
Signal to Noise ratio125 dB
-
Total Harmonic Distortion (THD+N)0.0004 %
-
Intermodulation Distortion (IMD)0.0003 %
-
Headphone output power (600 Ω / 300 Ω / 50 Ω)100 mW / 200 mW / 0.8 W
-
Headphone output THD0.005 %
-
Headphone output IMD0.005 %
-
Power Consumption @ Idle25 W
-
Power Consumption @ Standby20 W
-
Power Consumption @ low power Standby4 W
-
AC Power Requirements100-240V / 50-60Hz
-
Shipping weight22 lb / 10 kg
-
Dimensions (width x height x depth)16.9 x 3.5 x 13.1 in
-
42.9 x 8.9 x 33.3 cm
