Moon by Simaudio 650D CD player / Dac

$9,00000

Please Call/Email to order -  Item Not Available for Online Purchase

405-795-3462

info@referenceanalog.com

Proprietary CD drive system mounted on our MQuattro gel-based 4-point floating suspension for vibration damping.
True 32-bit asynchronous Digital-to-Analog converter.


The MOON 650D features “MQA pass-through” capability. The MQA encoded data on the disc will be outputted on the digital output such that an MQA certified DAC will decode it and give you the full performance that MQA offers.


Design features



  • Proprietary CD drive system mounted on our M-Quattro gel-based 4-point floating suspension.
  • Separate digital and analog power supplies, each with their own toroidal transformer.
  • Power supply voltage regulation includes i2 DCf (Independent Inductive DC Filtering); 1 inductor for each and every IC in the audio circuit’s signal path – 18 stages in all.
  • Four (4) digital inputs (AES/EBU, S/PDIF, TosLink and USB) allowing for a connection to virtually any digital source.
  • Two (2) digital outputs – AES/EBU and S/PDIF.
  • Fully compatible with 820S external power supply.



Specifications



  • Frequency response (full range)2Hz - 100kHz +0/-3dB
  • THD @ 1kHz, 0dBFS (A-weighted)0.0001%
  • Intermodulation distortion0.0001%
  • Dynamic Range120dB
  • Signal-to-noise Ratio120dB @ full output
  • Channel Separation116dB
  • Intrinsic Jitter1 picosecond RMS
  • Analog Output @ 0dBFS2.0 Volts
  • Analog output impedance100Ω
  • Bit-depth range16 - 24 bits
  • Sampling frequency rates 44.1 - 192kHz
  • Shipping weight35 lb / 16 kg
  • Dimensions (width x height x depth)18.75 x 4.0 x 16.8 in
